1. |
Support IEFT RFC4533 Structure-Agnostic TDM over Packet (SAToP), Metro Ethernet Forum MEF8. |
2. |
4 x E1/T1 NRZ Serial Interface with LOS/AIS detection. |
3. |
Use Raw Encapsulation method for PDH payload over IP packet. |
4. |
Support Circuit Emulation Service over IP. |
5. |
Comply with IEFT draft standard for CESoPSN and SAToP; Metro Ethernet Forum MEF8 IA. |
6. |
Support both Point-to-Point and Point-to-Multipoint operation. |
7. |
Support 4 independent Adaptive Clock recovery block for Ingress PDH (PSN -> TDM) clock generation. Recovered clock jitter is compliant to ITU-T G.824/ANSI T1.105 (E1/T1 Jitter Control). |
8. |
Independent configurable jitter buffer depth to compensate up to 250ms of Packet Delay Variation. |
9. |
Lost packets processing/compensation via PW (Pseudo Wire) control field Sequence Number. |
10. |
Provide Subscriber side Data traffic bandwidth control to guarantee enough TDM payload bandwidth. |
11. |
PDH LOS detection triggered PW L field or payload AIS generation at Egress direction (TDM -> PSN). |
12. |
Configurable IEEE 802.3 DA/SA assignment. |
13. |
Configuration can be made through RS-232 console port or Easy-to-use GUI (Graphic User Interface). |
